HYT-TC-6

Highlights

diagram indicating highlights of HYT-TC-6

    Functions

    Uncooled VOx Technology

    Hytera thermal cameras use uncooled VOx sensor technology. Their small size and better performance make them a cost-effective solution for thermal security.

    High Sensitivity

    High thermal sensitivity (<40 mK) allows cameras to capture more im-age details and temperature difference information.

    Protection

    ProtectionThe The camera allows for wide input voltage tolerance, suitable for the most unstable conditions for outdoor applications. Its 6KV lightning rat-ing provides effective protection for both the camera and its structure against lightning.

    Body Temperature Measurement

    Hytera thermal cameras characterized by non-contact, multi-objective, rapid, and no risk to temperature testers, etc. It can be conveniently deployed in public places with dense personnel, and can be used for efficient and safe preliminary screening of temperature anomalies.

    Accessories for HYT-TC-6

    Included as standard with HYT-TC-6 Included as standard with HYT-TC-6

    Systems that work with HYT-TC-6

    Technical Specifications

    Thermal

    Detector Type
    Vanadium oxide uncooled focal plane detector
    Effective Pixels
    400 × 300
    Pixel Pitch
    17 μm
    Spectral Range
    8 μm–14 μm
    Thermal Sensitivity (NETD)
    ≤40 mK
    Focal Length
    13 mm
    Field of View
    13 mm: horizontal: 30°, vertical: 22.6°
    Focus Mode
    Fixed-focal
    Aperture
    F1.0
    Digital Detail Enhancement (DDE)
    Yes
    Thermal Image Stabilization
    Electronic Image Stabilization
    AGC
    Auto; manual
    Noise Reduction
    2D NR; 3D NR
    Image Flip
    90°/180°/mirror
    Color Palettes
    18 color modes selectable such as Whitehot/Blackhot/Ironrow/Icefire.
    TemperatureMeasurement Range
    30°C ~+45°C
    Temperature Accuracy
    Max ±0.3°C with blackbody Max ±1°C without blackbody
    Temperature Mode
    Spot: 12 Line: 12 Area: 12 Support 12 rules simultaneously

    Visible

    Image Sensor
    1/2.8" 2M CMOS
    Effective Pixels
    1920(H)x1080(V)
    Electronic Shutter Speed
    1/1 ~ 1/30,000s
    Min. Illumination
    Color: 0.002Lux; B/W: 0.0002Lux; 0Lux (IR on)
    IR Distance
    35m
    IR On/Off Control
    Auto/Manual
    IR LEDs
    1
    Focal Length
    8mm
    Max Aperture
    F1.9
    Angle of View
    H: 40° V: 22°

    Audio and Video

    Video Compression
    H.265; H.264; H.264H; H.264B; MJPEG
    Resolution
    Thermal Main stream: (1280 × 1024/1024 × 768/640 × 480/256 × 192@), 1280 × 960 by default; Sub stream: (640 × 512/256 × 192@), 256 × 192 by default Visible Main stream: (1920 × 1080/1280 × 720/704 × 576@), 1920 × 1080 by default; Sub stream: (704 × 576/352 × 288@), 355 x 288 by default
    Audio Compression
    G.711a; G.711mu; AAC; PCM
    Image Encoding Format
    JPEG

    General Function

    Two-way Talk
    Yes
    Network Protocol
    HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP
    Region of Interest (ROI)
    Yes
    Edge Storage
    FTP; Micro SD card (256G, hot plug)
    Interoperability
    ONVIF; CGI; Hytera SDK
    Browser
    IE: IE8 and the later, and explorer with IE core Google: 42 and the earlier Firefox: 42 and the earlier Safari: 10 and the earlier
    User/Host
    20 channels at most (the total bandwidth 64M)
    Security
    Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access
    User Management
    Support 20 users at most and users are classified as two groups-administrator group and user group.
    Malfunction Detection
    Network disconnection; IP addresses conflict; SD card error (status or storage space)

    Port

    Analog Video Output
    1 channel of CVBS output with BNC port
    Network
    1 10M/100M Ethernet port (RJ-45)
    Alarm Input
    2 channels
    Alarm Output
    2 channels
    Audio Input
    1 channel
    Audio Output
    1 channel
    Alarm Linkage
    SD card recording/on-off output/ siren and light/email/PTZ/snapshot
    Alarm Event
    Motion detection/privacy mask/audio detection/SD card abnormality/network abnormality/anti-burn warning
    RS-485
    1 channel

    Power

    Power Supply
    12V±20% DC, 1.2A, PoE (802.3af), ePoE
    Power Consumption
    Basic: 5.0W Maximum: 12W (power adapter excluded)

    Environment

    Operating Temperature
    10°C to +30°C
    Operating Humidity
    ≤95%
    Self-Adaptive
    Auto heating to protect the chip under the cold environment

    Physical Characteristics

    Protection Grade
    IP67, anti-surge 6KV, anti-elctrostatic 8KV (touched by objects), anti-elctrostatic 15KV (air)
    Packaging Dimensions
    365 mm × 175 mm × 176 mm (14.37" × 6.89" × 6.93")
    Net Weight
    ≤1.4 kg (3.09 lb)
    Gross Weight
    ≤1.9 kg (4.19 lb)
    Power Adaptor
    Selectable
    Lens
    Contained

    Certification

    Certifications
    CE; FCC
